Chenyue NMRV 75 CY Series Worm Gearbox Reducer
87.99 USD ($)/Piece
Product Details:
- Usage Industrial
- Gear Type Worm Gears
- Material Iron
- Size 30.5*29.5*38
- Processing Type Die Casting
- Gear Tooth Profile Other
- Height 38 Centimeter (cm)
- Click to View more
X
Chenyue NMRV 75 CY Series Worm Gearbox Reducer Price And Quantity
- 87.99 USD ($)/Piece
- 1 Piece
Chenyue NMRV 75 CY Series Worm Gearbox Reducer Product Specifications
- 38 Centimeter (cm)
- Iron
- 29.5 Centimeter (cm)
- 30.5*29.5*38
- Worm
- 0.37kW-3kW
- Worm Gears
- 30.5 Centimeter (cm)
- Die Casting
- blue,green,gray
- Other
- Industrial
- High
- CYRV75 3 KW Worm Gearbox
- 80N.m-233N.m N-m
- 10 Kilograms (kg)
Chenyue NMRV 75 CY Series Worm Gearbox Reducer Trade Information
- Qingdao,Shanghai,Lianyungang
- Paypal, Delivery Point (DP), Telegraphic Transfer (T/T), Letter of Credit (L/C)
- 30000 Piece Per Month
- 3 Days
- Contact us for information regarding our sample policy
- Carton+Catalogue+Manual+PE Plastic Bag+QC Certificate+Anti-bump Filler+Desiccant+Engineering Plastic Tray
- Australia, North America, South America, Eastern Europe, Western Europe, Middle East, Asia, Africa, Central America
- All India
- CE/RoHS/IAF/CNAS/ISO9001/ISO45001/ISO14001
Product Description
Key features
ABBS/IEMENS and other high end motors can be installed together with our Warm gear reducer to be sold
WORM WHEEL ADOPTS HIGH QUALITY TIN Bronze LONG SERVICE LIFE AND MORE DURABILITY
Factory outlet provide video factory inspection
Speed ratio range from 5:1 to 100:1
Input shaft hole 14/19/22/ 24/28 mm
Output shaft hole 28 mm
Rated Input Speed 1400 rpm
Output Speed 145 rpm-290 rpm
Rated Input Power 0.37 kW-3 kW
Output Torque Range 80 N.m-233 N.m
Colors Blue or gray or according to customer required
Diecast aluminum alloy housing
Certification:RoHSCEIAFCNAS ISO9001ISO45001ISO14001
Flange round or square
Delivery time 1-3 daysfor ready goods we can deliver them within 2 days
Approximate gross weight 10 Kgpc
Key benefits
Maintenance free fully sealed no need fill oil for whole life
Good heat dissipation low temperature rise
Low noise smooth operation
Energy saving and high efficiency
Can be installed in any position and in all directions
Builtin fully synthetic lubricant no breather plug
Tip
The whole worm gearbox is warranted for one year
The starting date of the warranty period is subject to the date of the
product invoice please present the invoice when repairing
Beyond the warranty period or does not belong to the free warranty
products the company maintenance center is still dedicated to serve you
Contact detail
If you need special customization or have requirements for delivery time please contact sales managerchenyuetech@gmail.com, WhatsApp: +86 132 7517 8089
