CHENYUE NMRW,CYRW40 Worm Gearbox Reducer

Product Description

Key features
ABB/SIEMENS and other high-end motors can be installed together with our gearboxes to be sold
WORM WHEEL ADOPTS HIGH QUALITY TIN Bronze LONG SERVICE LIFE AND MORE DURABILITY.
Factory outlet provide video factory inspection
Speed ratio range: from 5:1 to 100:1
Input shaft/hole: 11/14 mm
Output shaft/hole: 18 mm
Rated Input Speed: 1400 rpm
Output Speed: 290 rpm
Rated Input motor : 0.09 kW-0.37 kW
Output Torque Range : 11 N.m-39 N.m
Colors:Blue or gray or according to customer required
Die-cast aluminum alloy housing
Certification: RoHS/CE/IAF/CNAS /ISO9001/ISO45001/ISO14001
Flange: round or square
Delivery time: 1-3 days(for ready goods,we can deliver them within 2 days)
Approximate gross weight: 3 Kg/pc

Key benefits
Maintenance-free,fully sealed(no need fill oil for whole life)
Good heat dissipation,low temperature rise
Low noise, smooth operation
Energy saving and high efficiency
Can be installed in any position and in all directions
Built-in fully synthetic lubricant, no breather plug,

Tip:
The whole Worm Drive Gearbox is warranted for one year
The starting date of the warranty period is subject to the date of the
product invoice, please present the invoice when repairing.
Beyond the warranty period or does not belong to the free warranty
products, the company's maintenance center is still dedicated to serve you.
