CHENYUE NMRV90 Worm Gearbox Heavy Duty Worm Gear Reducer Gearboxes, Input 19/22/24/28mm, Output 35mm, Speed Ratio 5:1 to 100:1, Free Maintenance CHENYUE NMRV90 Worm Gearbox Heavy Duty Worm Gear Reducer Gearboxes, Input 19/22/24/28mm, Output 35mm, Speed Ratio 5:1 to 100:1, Free Maintenance CHENYUE NMRV90 Worm Gearbox Heavy Duty Worm Gear Reducer Gearboxes, Input 19/22/24/28mm, Output 35mm, Speed Ratio 5:1 to 100:1, Free Maintenance CHENYUE NMRV90 Worm Gearbox Heavy Duty Worm Gear Reducer Gearboxes, Input 19/22/24/28mm, Output 35mm, Speed Ratio 5:1 to 100:1, Free Maintenance CHENYUE NMRV90 Worm Gearbox Heavy Duty Worm Gear Reducer Gearboxes, Input 19/22/24/28mm, Output 35mm, Speed Ratio 5:1 to 100:1, Free Maintenance CHENYUE NMRV90 Worm Gearbox Heavy Duty Worm Gear Reducer Gearboxes, Input 19/22/24/28mm, Output 35mm, Speed Ratio 5:1 to 100:1, Free Maintenance
CHENYUE NMRV90 Worm Gearbox Heavy Duty Worm Gear Reducer Gearboxes, Input 19/22/24/28mm, Output 35mm, Speed Ratio 5:1 to 100:1, Free Maintenance
CHENYUE NMRV90 Worm Gearbox Heavy Duty Worm Gear Reducer Gearboxes, Input 19/22/24/28mm, Output 35mm, Speed Ratio 5:1 to 100:1, Free Maintenance CHENYUE NMRV90 Worm Gearbox Heavy Duty Worm Gear Reducer Gearboxes, Input 19/22/24/28mm, Output 35mm, Speed Ratio 5:1 to 100:1, Free Maintenance CHENYUE NMRV90 Worm Gearbox Heavy Duty Worm Gear Reducer Gearboxes, Input 19/22/24/28mm, Output 35mm, Speed Ratio 5:1 to 100:1, Free Maintenance CHENYUE NMRV90 Worm Gearbox Heavy Duty Worm Gear Reducer Gearboxes, Input 19/22/24/28mm, Output 35mm, Speed Ratio 5:1 to 100:1, Free Maintenance CHENYUE NMRV90 Worm Gearbox Heavy Duty Worm Gear Reducer Gearboxes, Input 19/22/24/28mm, Output 35mm, Speed Ratio 5:1 to 100:1, Free Maintenance

CHENYUE NMRV90 Worm Gearbox Heavy Duty Worm Gear Reducer Gearboxes, Input 19/22/24/28mm, Output 35mm, Speed Ratio 5:1 to 100:1, Free Maintenance

131.99 USD ($)/Piece
Get a Price/Quote

Product Details:

  • Usage Industrial
  • Gear Type Worm Gears
  • Material Other
  • Processing Type Die Casting
  • Size 33.5*32.5*42
  • Gear Tooth Profile Other
  • Height 42 Centimeter (cm)
  • Click to View more
Request to Call Back Send Inquiry
X

CHENYUE NMRV90 Worm Gearbox Heavy Duty Worm Gear Reducer Gearboxes, Input 19/22/24/28mm, Output 35mm, Speed Ratio 5:1 to 100:1, Free Maintenance Price And Quantity

  • 1 Piece
  • 131.99 USD ($)/Piece

CHENYUE NMRV90 Worm Gearbox Heavy Duty Worm Gear Reducer Gearboxes, Input 19/22/24/28mm, Output 35mm, Speed Ratio 5:1 to 100:1, Free Maintenance Product Specifications

  • blue,green,gray
  • 33.5 Centimeter (cm)
  • 0.55kW-4kW
  • 42 Centimeter (cm)
  • Other
  • CYRV90 4 KW Worm Gearbox
  • 117N-m-352N-m N-m
  • Die Casting
  • High
  • Industrial
  • 32.5 Centimeter (cm)
  • Worm Gears
  • Other
  • 33.5*32.5*42
  • 14 Kilograms (kg)
  • Worm

CHENYUE NMRV90 Worm Gearbox Heavy Duty Worm Gear Reducer Gearboxes, Input 19/22/24/28mm, Output 35mm, Speed Ratio 5:1 to 100:1, Free Maintenance Trade Information

  • Qingdao,Shanghai,Lianyungang
  • Paypal, Delivery Point (DP), Telegraphic Transfer (T/T), Letter of Credit (L/C)
  • 30000 Piece Per Month
  • 3 Days
  • Contact us for information regarding our sample policy
  • Carton+Catalogue+Manual+PE Plastic Bag+QC Certificate+Anti-bump Filler+Desiccant+Engineering Plastic Tray
  • Asia, Australia, Central America, North America, South America, Eastern Europe, Western Europe, Middle East, Africa
  • All India
  • CE/RoHS/IAF/CNAS/ISO9001/ISO45001/ISO14001

Product Description

Key features
ABBSIEMENS and other highend motors can be installed together with our gearboxes to be sold
WORM WHEEL ADOPTS HIGH QUALITY TIN Bronze LONG SERVICE LIFE AND MORE DURABILITY
Factory outlet provide video factory inspection
Speed ratio range from 5:1 to 100:1
Input shaft hole 19/22/24/ 28 mm
Output shaft hole 35 mm
Input Speed 1400 rpm
Output Speed 290 rpm
Rated Input Power: 0.55 kW-4 kW
Output Torque Range 117 N.m-352 N.m
Colors Blue or gray or green or according to customer required
Diecast aluminum alloy housing
Certification: RoHSCEIAFCNASISO9001ISO45001ISO14001
Flange round or square
Delivery time 1-3 days for ready goods we can deliver them within 2 days
Approximate gross weight 14 Kgpc

Key benefits
Maintenance free fully sealed no need fill oil for whole life
Good heat dissipation low temperature rise
Low noise smooth operation
Energy saving and high efficiency
Can be installed in any position and in all directions
Builtin fully synthetic lubricant no breather plug

Tip
The whole Worm Drive Gearbox is warranted for one year
The starting date of the warranty period is subject to the date of the
product invoice please present the invoice when repairing
Beyond the warranty period or does not belong to the free warranty
products the company maintenance center is still dedicated to serve you

Contact detail
If you need special customization or have requirements for delivery time please contact sales manager chenyuetech@gmail.com WhatsApp +86 15221517542 Service 86 400 019 2928
