CHENYUE Worm Gearbox CYWF80 speed ratio from 5:1 to 100:1 free maintenance, fully sealed, No need to refuel for life CHENYUE Worm Gearbox CYWF80 speed ratio from 5:1 to 100:1 free maintenance, fully sealed, No need to refuel for life CHENYUE Worm Gearbox CYWF80 speed ratio from 5:1 to 100:1 free maintenance, fully sealed, No need to refuel for life CHENYUE Worm Gearbox CYWF80 speed ratio from 5:1 to 100:1 free maintenance, fully sealed, No need to refuel for life CHENYUE Worm Gearbox CYWF80 speed ratio from 5:1 to 100:1 free maintenance, fully sealed, No need to refuel for life CHENYUE Worm Gearbox CYWF80 speed ratio from 5:1 to 100:1 free maintenance, fully sealed, No need to refuel for life
CHENYUE Worm Gearbox CYWF80 speed ratio from 5:1 to 100:1 free maintenance, fully sealed, No need to refuel for life
CHENYUE Worm Gearbox CYWF80 speed ratio from 5:1 to 100:1 free maintenance, fully sealed, No need to refuel for life CHENYUE Worm Gearbox CYWF80 speed ratio from 5:1 to 100:1 free maintenance, fully sealed, No need to refuel for life CHENYUE Worm Gearbox CYWF80 speed ratio from 5:1 to 100:1 free maintenance, fully sealed, No need to refuel for life CHENYUE Worm Gearbox CYWF80 speed ratio from 5:1 to 100:1 free maintenance, fully sealed, No need to refuel for life CHENYUE Worm Gearbox CYWF80 speed ratio from 5:1 to 100:1 free maintenance, fully sealed, No need to refuel for life

CHENYUE Worm Gearbox CYWF80 speed ratio from 5:1 to 100:1 free maintenance, fully sealed, No need to refuel for life

659.99 USD ($)/Piece
Get a Price/Quote

Product Details:

  • Gear Type Worm Gears
  • Usage industrial
  • Material Other
  • Processing Type Die Casting
  • Size 30.5*29.5*38
  • Height 38 Centimeter (cm)
  • Gear Tooth Profile Other
  • Click to View more
Request to Call Back Send Inquiry
X

CHENYUE Worm Gearbox CYWF80 speed ratio from 5:1 to 100:1 free maintenance, fully sealed, No need to refuel for life Price And Quantity

  • 659.99 USD ($)/Piece
  • 1 Piece

CHENYUE Worm Gearbox CYWF80 speed ratio from 5:1 to 100:1 free maintenance, fully sealed, No need to refuel for life Product Specifications

  • CYWF80 7.5 KW Worm Gearbox
  • 0.75kW-7.5kW
  • 30.5*29.5*38
  • 30.5 Centimeter (cm)
  • blue,green,gray
  • 38 Centimeter (cm)
  • industrial
  • 24.9 Kilograms (kg)
  • Die Casting
  • 200N m-647N m N-m
  • Other
  • Worm Gears
  • Worm
  • High
  • Other
  • 29.5 Centimeter (cm)

CHENYUE Worm Gearbox CYWF80 speed ratio from 5:1 to 100:1 free maintenance, fully sealed, No need to refuel for life Trade Information

  • Paypal, Delivery Point (DP), Telegraphic Transfer (T/T), Letter of Credit (L/C)
  • 30000 Piece Per Month
  • 3 Days
  • Carton+Catalogue+Manual+PE Plastic Bag+QC Certificate+Anti-bump Filler+Desiccant+Engineering Plastic Tray
  • Asia, Australia, Central America, North America, South America, Eastern Europe, Western Europe, Middle East, Africa
  • All India
  • CE/RoHS/IAF/CNAS/ISO9001/ISO45001/ISO14001

Product Description

Key features
High-end motors can be installed together with our gearboxes to be sold
Factory outlet
Provide video-outgoing inspection
Speed ratio range: from 5:1 to 100:1
Input hole: 19/24/28/38 mm
Output hole: from 71 mm to 80 mm
Rated Input motor: 0.75 kW7.5 kW
Output Torque Range: 200 Nm647 Nm
Rated input motor speed: 1400 r/min
Rated output motor speed: 14 rpm--280 rpm
Colors: Blue or grey or green or according to customer required
Die-cast aluminum alloy housing
Worm wheel adopts high quality Tin Bronze
Certification:RoHS/CE/IAF/CNAS/ISO9001/ISO45001/ISO14001
Bipolar reducers: available
Flange: round or square
Mounting orientation:B3 B6 B7 B8 V5 V6
Delivery time: 1-3 days
Approximate gross weight:25.5 Kg/pc
Key benefits
Maintenance-free, fully sealed(no need fill oil for whole life)
Good heat dissipation
Low temperature rise
Low noise, smooth operation
Long service life and more durability
Energy saving and high efficiency
Can be installed in any position and in all directions
Built-in fully synthetic lubricant
Tip:
The whole worm gearbox is warranted for one year.
The starting date of the warranty period is subject to the date of the product invoice, please present the invoice when repairing.
Beyond the warranty period or does not belong to the free warranty products, the company's maintenance center is still dedicated to serve you.
